烟用醋酸纤维素基超轻气凝胶的构筑及表征
Fabrication and characterization of cigarette butt-derived cellulose acetate-based ultralight aerogels for tobacco applications
-
摘要: 【目的】 实现烟蒂中醋酸纤维素的资源化利用,将其转化为高附加值材料,并探究其结构与性能特征。【方法】 采用溶剂清洗法制备回收醋酸纤维素(R-CA),结合静电纺丝技术将R-CA转化为纳米纤维,并采用冷冻干燥成型工艺进一步加工成气凝胶。采用傅里叶变换红外光谱仪、热重分析仪和差示扫描量热仪等对R-CA纳米纤维膜及其气凝胶的结构与性能进行分析。【结果】 R-CA与商用醋酸纤维素具有相似的化学结构,最大热降解温度相近,分别为355.0 ℃和357.5 ℃,说明纯化过程不影响R-CA的分子结构与热力学性能。随着R-CA纺丝浓度的增加,纤维形貌由串珠结构转变为均匀光滑的纳米纤维,纺丝浓度为17%时所得纤维直径分布最均匀,平均直径为336.8 nm。基于此纺丝浓度制备的纳米纤维经分散、均质化、冷冻干燥后,成功构筑三维网络结构气凝胶,其表观密度为8.59~11.55 mg/cm3,孔隙率高于99%,表现出极低密度和高孔隙特性。【结论】 本研究可有效回收R-CA并制备高性能气凝胶,为烟蒂资源化利用提供参考。Abstract: 【Objective】 To achieve the resource valorization of cellulose acetate (CA) from cigarette butts by converting it into high value-added materials, and to investigate its structural and performance characteristics. 【Methods】 Recycled cellulose acetate (R-CA) was prepared via solvent washing. R-CA was then converted into nanofibers by electrospinning, and further fabricated into aerogels in one step through freeze-drying. The structure and properties of the R-CA nanofiber membranes and corresponding aerogels were characterized by Fourier transform infrared spectroscopy (FTIR), thermogravimetric analysis (TGA), and differential scanning calorimetry (DSC). 【Results】 R-CA exhibited a similar chemical structure to commercial CA, with similar peak thermal degradation temperatures of 355.0 ℃ and 357.5 ℃, respectively. This indicates that the purification process did not alter the molecular structure or thermal properties of R-CA. With increasing R-CA electrospinning concentration, the fiber morphology evolved from beaded structures to uniform and smooth nanofibers. The fibers obtained at 17% concentration showed the most uniform diameter distribution, with an average diameter of 336.8 nm. Nanofibers prepared at this optimal concentration were subjected to dispersion, homogenization, and freeze-drying to successfully form a 3D network aerogel. The aerogel had an apparent density of 8.59~11.55 mg/cm3 and a porosity above 99%, showing ultra-low density and high porosity. 【Conclusion】 This study enables the efficient recovery of R-CA and the preparation of high-performance aerogels, offering a valuable reference for the resource valorization of cigarette butts.
-
Key words:
- cigarette butt /
- cellulose acetate /
- electrospinning /
- nanofiber membrane /
- aerogel
-
-
[1]
DE CESARIS M G,FELLI N,ANTONELLI L,et al.Recovery of cellulose acetate bioplastic from cigarette butts:Realization of a sustainable sorbent for water remediation[J].Science of The Total Environment,2024,929:172677.
-
[2]
周慧敏,鲁杰,程意,等.醋酸纤维素的改性及应用研究进展[J].林产化学与工业,2020,40(4): 1-8.
ZHOU H M,LU J,CHENG Y,et al.Research progress on modification and application of cellulose acetate [J].Chemistry and Industry of Forest Products,2020,40(4):1-8. -
[3]
MAHTO A,HALAKARNI M A,MARADDI A,et al.Upcycling cellulose acetate from discarded cigarette butts:Conversion of contaminated microfibers into loose-nanofiltration membranes for selective separation[J].Desalination,2022,535:115807.
-
[4]
BEHVANDI D,AREFIZADEH M,GHAEMI A,et al.Optimization of hydrochar production from cigarette filters for enhanced CO2 adsorption[J].Results in Engineering,2024,22:102308.
-
[5]
LIU W M,CUI M K,SHEN Y Q,et al.Waste cigarette filter as nanofibrous membranes for on-demand immiscible oil/water mixtures and emulsions separation[J].Journal of Colloid and Interface Science,2019,549:114-122.
-
[6]
胡杨彪.醋酸纤维素气凝胶的可控制备及其杂化材料性能研究[D].赣州: 江西理工大学,2022. HU Y B.Controllable preparation and properties of diacetate aerogelsand their hybrid materials[D].Ganzhou:Jiangxi University of Science and Technology,2022.
-
[7]
黄兴.醋酸纤维素气凝胶制备及性能研究[D].长沙:国防科学技术大学,2016. HUANG X.Preparation and characterization of celluloseace-tate aerogels[D].Changsha:National University of Defense Technology,2016.
-
[8]
SOLEIMANI F,DOBARADARAN S,DE-LA-TORRE G E,et al.Content of toxic components of cigarette,cigarette smoke vs cigarette butts:A comprehensive systematic review[J].Science of The Total Environment,2022,813:152667.
-
[9]
FAHANWI A N,YASIR M,NGUYEN H T,et al.In situ polyaniline polymerization on electrospun cellulose acetate nanofibers derived from recycled waste filter butts of cigarettes for the enhanced removal of methyl orange and rhodamine[J].Chemical Engineering Research and Design,2024,201:18-30.
-
[10]
KHAN M R,LIAO S Q,FAROOQ A,et al.Regeneration and modification of cellulose acetate from cigarette waste:Biomedical potential by encapsulation of tetracycline hydrochloride[J].International Journal of Biological Macromolecules,2023,250:126266.
-
[11]
D'URSO F,IACCARINO P,GIORDANO M,et al.A preliminary study on 3D printing feedstock derived from cellulose recovered from cigarette butts[J].Cellulose,2024,31(8):5097-5114.
-
[12]
DE FENZO A,GIORDANO M,SANSONE L.A clean process for obtaining high-quality cellulose acetate from cigarette butts[J].Materials,2020,13(21):4710.
-
[13]
BEHZADI M.Facile fabrication and application of poly(ortho-phenetidine) nanocomposite coating for solid-phase microextraction of carcinogenic polycyclic aromatic hydrocarbons from wastewaters[J].Ecotoxicology and Environmental Safety,2021,208:111568.
-
[14]
MATTIODA A L,HUDGINS D M,BOERSMA C,et al.The NASA ames PAH IR spectroscopic database:The laboratory spectra[J].The Astrophysical Journal Supplement Series,2020,251(2):22.
-
[15]
BENAZZOUZ A,DUDOGNON E,CORREIA N T,et al.Interactions underpinning the plasticization of a polymer matrix:A dynamic and structural analysis of DMP-plasticized cellulose acetate[J].Cellulose,2017,24(2):487-503.
-
[16]
高立斌,张素英,史晟,等.醋酸纤维素的制备及其结构与性能[J].应用化工,2020,49(1): 55-59.
GAO L B,ZHANG S Y,SHI S,et al.Synthesis,structure and properties of cellulose acetate[J].Applied Chemical Industry,2020,49(1):55-59. -
[17]
汪超,龙义强,张骋昊,等.超临界CO2/乙醇共溶剂处理对醋酸纤维素结构的影响[J].塑料工业,2023,51(1):74-79.
WANG C,LONG Y Q,ZHANG C C,et al.Effect of supercritical CO2 and ethanol as a cosolvent treatment on the structure of cellulose acetate[J].China Plastics Industry,2023,51(1):74-79. -
[18]
MAJUMDER S,MATIN M A,SHARIF A,et al.Understanding solubility,spinnability and electrospinning behaviour of cellulose acetate using different solvent systems[J].Bulletin of Materials Science,2019,42(4):171.
-
[19]
LEE H,NISHINO M,SOHN D,et al.Control of the morphology of cellulose acetate nanofibers via electrospinning[J].Cellulose,2018,25(5):2829-2837.
-
[20]
HWANG Y J,CHOI S,KIM H S.Structural deformation of PVDF nanoweb due to electrospinning behavior affected by solvent ratio[J].e-Polymers,2018,18(4): 339-345.
-
[21]
尹思迪.原位交联构筑轻质超弹醋酸纤维素气凝胶及其保暖性能[D].上海:东华大学,2022. YIN S D.In-situ crosslinking of lightweight super-elastic cellulose acetate aerogel and its warmth retention property[D].Shanghai:Donghua University,2022.
-
[22]
杜浩田,李姝姝,周宏伟.醋酸纤维素纳米纤维薄膜的制备及表征[J].西安工业大学学报,2022,42(5):460-467.
DU H T,LI S S,ZHOU H W.Preparation and characterization of cellulose acetate nanofiber films[J].Journal of Xi'an Technological University,2022,42(5):460-467. -
[23]
刘慧.静电纺丝醋酸纤维素复合纳米纤维膜制备及其抗菌性能研究[D].秦皇岛:燕山大学,2022. LIU H.Preparation and antibacterial properties of electrospun cellulose acetate composite nanofiber membrane[D].Qinhuangdao:Yanshan University,2022.
-
