Kriging近似模型在副车架轻量化设计中的应用试验
Application experiment of the Kriging approximate model in lightweight design of subframe
-
摘要: 针对现有副车架轻量化设计要么优化效果不理想、要么对模型精度要求较高的问题，采用Kriging近似模型替代物理模型对副车架进行了轻量化设计：利用拉丁超立方试验设计方法对副车架的重要特征点进行采样，建立Kriging近似模型，并将副车架参数化；以副车架质量为目标函数，选取11个厚度尺寸作为设计变量对其进行优化，通过约400次的迭代得到最优解.优化后的副车架质量为11.3 kg，较优化前减轻10.3%，跳动工况下最大应力值仍满足屈服条件，且自由模态频率也满足模态要求，较好地实现了轻量化设计.该方法的优点在于既实现了较好的优化效果，又无需在不同软件间转换，有效避免了模型的失真.
-
关键词:
- 副车架 /
- Kriging近似模型 /
- 轻量化设计
Abstract: The light weight design of the subframe is either not ideal, or the accuracy of the model should be higher. To deal with the problems, the Kriging approximate model was used to make a lightweight design for the subframe.Firstly,the Latin hypercube sampling test design method was used to sample the important feature points of the subframe, and the Kriging approximate model was combined to parameterize the subframe. Then, the fatigue of subframe was taken as the target parameter,and 11 thickness dimensions were selected as design variables and optimized. The optimal solution was obtained through about 400 iterations, and the optimized subframe quality was 11.3 kg, which was reduced by 10.3% compared with that before optimization. The maximum stress value under beating condition still satisfied the yield condition, and the free model frequency also met the model requirement, which realized the lightweight design better. The advantage of this method was that it not only achieved better optimization results, but also did not need to transform among different softwares and effectively avoided the distortion of the model.-
Key words:
- subframe /
- Kriging approximate model /
- lightweight design
-
-
[1]
汪伟,莫蓉,范庆明.基于响应面模型的跨音速转子叶片气动优化设计研究[J].西安工业大学学报,2013,33(2):114.
-
[2]
张勇.基于近似模型的汽车轻量化优化设计方法[D].长沙:湖南大学,2009.
-
[3]
张超.基于克里金(Kriging)近似模型的风管多阀门优化调节方法[J].暖通空调,2015,45(7):96.
-
[4]
韩忠华.Kriging模型及代理优化算法研究进展[J].航空学报,2016,37(11):3197.
-
[5]
许瑞飞,宋文萍,韩忠华.改进Kriging模型在翼型气动优化设计中的应用研究[J].西北工业大学学报,2010(4):503.
-
[6]
李锦,苏小平,王宏楠,等.基于灵敏度分析的轿车副车架轻量化研究[J].机械科学与技术,2013,32(11):1650.
-
[7]
丁荣,苏小平,王宏楠.轿车副车架轻量化设计[J].机械设计,2015,32(3):37.
-
[8]
王卫,王东方,缪小冬,等.基于Isight的轿车副车架优化设计[J].河南科技大学学报(自然科学版),2016,37(2):26.
-
[9]
高月华.基于Kriging代理模型的优化设计方法及其在注塑成型中的应用[D].大连:大连理工大学,2009.
-
[10]
操安喜,刘蔚,崔维成.载人潜水器耐压球壳的多目标优化设计[J].中国造船,2007(3):107.
-
[11]
李飞.代理模型预测研究及其在叶轮机械中的应用[D].大连:大连理工大学,2014.
-
[12]
于海莲,王永泉,陈花玲,等.响应面模型与多目标遗传算法相结合的机床立柱参数优化[J].西安交通大学学报,2012,46(11):80.
-
