WO3纳米棒/石墨烯复合材料的制备及其气敏性能研究
Synthesis and gas-sensing properties of WO3 nanorods/graphene composites
-
摘要: 以钨酸钠和盐酸为原料、草酸和硫酸钠为辅助剂,采用水热法制备纯WO3,进一步掺杂氧化石墨烯(GO)制备WO3纳米棒/石墨烯复合材料.通过XRD,FE-SEM,RAMAN,FTIR等手段对不同GO掺杂量的WO3纳米棒/石墨烯复合材料进行表征,并采用静态配气法对该材料进行气敏性能测试.结果表明,纯WO3为单斜晶相,WO3纳米棒/石墨烯复合材料为四方晶相,且随着GO掺杂量的增加,纳米棒的长径比逐渐增大;当GO掺杂量为1.0 wt%时,复合材料的气敏性能较好,加热电压为2.96 V(约155℃),对5×10-6 H2的灵敏度达1.779,响应和恢复时间分别为3 s和4 s.
-
关键词:
- WO3纳米棒/石墨烯复合材料 /
- 水热法 /
- 气敏性能
Abstract: Using sodium tungstate and hydrochloric acid as raw materials, oxalic acid and sodium sulfate as auxiliary agents, WO3 nanorods/graphene composites had been synthesized by hydrothermal method. The as-synthesized samples were characterized by XRD, FE-SEM, RAMAN and FTIR. Gas-sensing characteristics of the materials had been tested by static state method. The results illustrated that the as-synthesized pure WO3 had monoclinic phase and the WO3/graphenenanomaterial had tetragonal phase. The length-diameter ratio of the materials increased when the amounts of graphene oxide (GO) increased, and the 1.0 wt% WO3/graphenenanocomposite had a good gas-sensing property. Its sensitivity could reach 1.779 of 5×10-6 H2 at 2.96 V working voltage(about 155℃). And this time, the response and recovery time was 3 s and 4 s, respectively.-
Key words:
- WO3 nanorods/graphene composite /
- hydrothermal /
- gas-sensing performance
-
-
[1]
Liu B Q,Tang D S,Zhou Y,et al.Electrical characterization of H2S adsorption on hexagonal WO3 nanowire at room temperature[J].Journal of Applied Physics,2014,116(16):164310.
-
[2]
An X Q,Yu J C,Wang Y,et al.WO3 nanorods/grapheme nanocomposites for high-efficiency visible-light-driven photocatalysis and NO2 gas sensing[J].Journal of Materials Chemistry,2012,22(17):8525.
-
[3]
Huang X L,Hu N T,Gao R G,et al.Reduced graphene oxide-polyaniline hybrid:preparation,characterization and its applications for ammonia gas sensing[J].Journal of Materials Chemistry,2012,22(42):22488.
-
[4]
Yoon H J,Jun D H,Yang J H,et al.Carbon dioxide gas sensor using a graphene sheet[J].Sensors and Actuators B:Chemical,2011,157(1):310.
-
[5]
Anand K, Singh O, Singh M P, et al.Hydrogen sensor based on graphene/ZnO nanocomposite[J].Sensors and Actuators B:Chemical,2014,195:409.
-
[6]
Yang T S,Lin Z R,Wong M S.Structures and electrochromic properties of tungsten oxide films prepared by magnetron sputtering[J].Applied Surface Science,2005,252(5):2029.
-
[7]
Stankovich S,Dikin D A,Piner R D,et al.Synthesis of graphene-based nanosheets via chemical reduction of exfoliated graphite oxide[J].Carbon,2007,45(7):1558.
-
[8]
Chu X F,Hu T,Gao F,et al.Gas sensing properties of graphene-WO3 composites prepared by hydrothermal method[J].Materials Science and Engineering:B,2015,193:97.
-
[9]
Qiu Y C,Xu G L,Kuang Q,et al.Hierarchical WO3 flowers comprising porous single-crystalline nanoplates show enhanced lithium storage and photocatalysis[J].Nano Research,2012,5(11):826.
-
