基于TEMPO氧化纤维的功能性滤棒的制备及其应用研究
Research on functional filter rod based on TEMPO oxidized fiber
-
摘要: 基于传统造纸法再造烟叶生产技术,结合2,2,6,6-四甲基哌啶-1-氧自由基(TEMPO)氧化纤维改性技术,制备绿色低碳植物纤维功能性滤棒,并将其应用于常规烟支进行感官评价研究。结果表明,制备植物纤维功能性滤棒的适宜条件为:m(针叶木纤维):m(醋酸纤维)=8 ∶ 2、TEMPO用量0.01 mmol/g、打浆度(25±2)°SR;在此条件下,滤棒原纸定量45 g/m2,松厚度2.88 cm3/g,透气度93 μm/(Pa· s),湿抗张指数3.073 N· m/g;涂布的植物纤维功能性滤棒卷烟的圆周、圆度、硬度和吸阻分别约为24.14 mm、0.39 mm、87.2%和331 mm H2O,均符合卷烟企业滤棒标准(圆周(24±0.20) mm、圆度≤ 0.40 mm、硬度≥ 82.0%和吸阻(310±30) mm H2O)。与传统纯醋纤滤棒相比,涂布的植物纤维功能性滤棒卷烟的感官评价总分相差不大,降低了2分,但主流烟气中有害成分的释放量均明显降低。因此,本研究制备的植物纤维功能性滤棒性能均能达到标准要求,这为绿色低碳、生物可降解和加香烟用滤棒的开发开辟了新途径。
-
关键词:
- 功能性滤棒 /
- TEMPO氧化纤维改性技术 /
- 物理指标 /
- 烟气指标 /
- 感官评价
Abstract: Based on the traditional papermaking process for reconstituted tobacco, combined with 2, 2, 6, 6- tetramethylpiperidine-1-oxide free radical (TEMPO)-mediated fiber oxidation modification technology, functional filter rods made from green and low-carbon plant fibers were prepared and applied to conventional cigarettes for sensory evaluation studies. The results showed that the optimal conditions for preparing the plant fiber-based functional filter rods were as follows: a mass ratio of softwood fiber to acetate fiber of 8:2, a TEMPO dosage of 0. 01 mmol/g, and a beating degree of (25±2) °SR. Under these conditions, the base paper of the filter rod had a basis weight of 45 g/m2, a bulk of 2. 88 cm3/g, an air permeability of 93 μm/(Pa·s), and a wet tensile index of 3. 073 N · m/g. The coated plant fiber-based functional filter rod cigarettes exhibited a circumference, roundness, hardness, and pressure drop of approximately 24. 14 mm, 0. 39 mm, 87. 2%, and 331 mm H2O, respectively, all meeting the filter rod standards of cigarette enterprises (circumference: (24 ±0.20) mm, roundness: ≤ 0. 40 mm, hardness: ≥ 82. 0%, and pressure drop: (310 ±30) mm H2O). Compared with traditional pure acetate filter rods, the total sensory evaluation score of cigarettes with coated plant fiber-based functional filter rods showed little difference, decreasing by only 2 points, while the release of harmful components in the mainstream smoke was significantly reduced. Therefore, the performance of the plant fiber-based functional filter rods prepared in this study can meet the standard requirements, which opens up a new avenue for the development of green, low-carbon, biodegradable, and flavor-enhanced cigarette filter rods.-
Key words:
- functional filter stick /
- TEMPO modification /
- physical indicator /
- smoke indicator /
- sensory evaluation
-
-
[1]
殷沛沛,刘莹莹,赵梦醒,等.不同外加纤维对烟草复合滤嘴棒用纸性能的影响[J].天津科技大学学报, 2024,39(3):41-48
,55. -
[2]
HUANG Z,LIU H,ZHOU W J,et al. Cellulose acetate filter rods tuned by surface engineering modification for typical smoke components adsorption[J]. E-Polymers,2024, 24(1):20230054.
-
[3]
邬晓龙,吕惠娇,刘丽婷,等.香烟滤嘴用纤维过滤材料的研究现状[J].染整技术,2023,45(8):12-15.
-
[4]
高一洲.醋酸纤维素及其衍生物的制备与应用进展[J].精细石油化工进展,2024,25(6):46-52.
-
[5]
赵金涛,林瑜,张云龙,等.一种再造烟叶纸质滤棒的开发研究[J].林产工业,2023,60(7):51-57.
-
[6]
刘晶,冯涛,张文军,等.纸质嘴棒及常规嘴棒的现状探讨分析[J].黑龙江造纸,2020,48(4):10-13.
-
[7]
邓少鹏,杨光远,彭三文,等.纸质滤棒结构重组实验及产品性能研究[J].造纸装备及材料,2024,53(10):1-3.
-
[8]
熊姗姗,张志龙,肖维毅,等.压纹工艺对纸质滤棒性能的影响[J].纸和造纸,2020,39(4):13-16.
-
[9]
尹嵩,燕宁宁,沈靖轩,等.功能性纤维在纸质滤棒中的应用研究[J].合成纤维工业, 2016, 39(1):39-41
,47. -
[10]
王健.烟用嘴棒填充纸的工艺改进及功能化研究[D].北京:中国制浆造纸研究院,2023.
-
[11]
邬宪娜,张兆琳.纸嘴棒原纸的半干起皱法生产技术[J].中华纸业,2021,42(10):52-54.
-
[12]
王健,刘文,朝鲁门,等.烟用滤嘴棒功能化改进及填充纸的技术发展[J].中国造纸,2023,42(2):102-109.
-
[13]
DE NOOY A E J, BESEMER A C, VAN BEKKUM H. Highly selective nitroxyl radical-mediated oxidation of primary alcohol groups in water-soluble glucans[J]. Carbohydrate Research,1995,269(1):89-98.
-
[14]
SAITO T,ISOGAI A. Wet strength improvement of TEMPO-oxidized cellulose sheets prepared with cationic polymers[J]. Industrial&Engineering Chemistry Research, 2007,46(3):773-780.
-
[15]
国家市场监督管理总局,国家标准化管理委员会.纸和纸板抗张强度的测定恒速拉伸法:GB/T 12914-2018[S].北京:中国标准出版社,2019.
-
[16]
中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.纸和纸板浸水后抗张强度的测定:GB/T 465. 2-2008[S].北京:中国标准出版社,2008.
-
[17]
中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.纸和纸板透气度的测定:GB/T 458-2008[S].北京:中国标准出版社,2009.
-
[18]
中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.纸柔软度的测定:GB/T 8942-2016[S].北京:中国标准出版社,2016.
-
[19]
中华人民共和国国家质量监督检验检疫总局.纸和纸板厚度的测定:GB/T 451. 3-2002[S].北京:中国标准出版社,2002.
-
[20]
SEGAL L,CREELY J J,MARTIN A E Jr,et al. An empirical method for estimating the degree of crystallinity of native cellulose using the X-ray diffractometer[J]. Textile Research Journal,1959,29(10):786-794.
-
[21]
Technical Association of the Pulp and Paper Industry. Carboxyl content of pulp:TAPPI T237cm-98[S]. Atlanta:Chemical Properties Committee of the Process and Product Quality Division,1998.
-
[22]
湖北中烟工业有限责任公司.烟用材料烟用滤棒040100烟用滤棒技术标准:QB/HBZY. WZ. CL. LB-040100-0001[S].
-
[23]
国家烟草专卖局.卷烟主流烟气中氨的测定离子色谱法:YC/T 377-2010[S].北京:中国标准出版社,2011.
-
[24]
-
[25]
-
[26]
中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.卷烟烟气气相中一氧化碳的测定非散射红外法:GB/T 23356-2009[S].北京:中国标准出版社,2009.
-
[27]
国家烟草专卖局.卷烟主流烟气中氰化氢的测定连续流动法:YC/T 253-2008[S].北京:中国标准出版社,2008.
-
[28]
中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.卷烟主流烟气总粒相物中烟草特有N-亚硝胺的测定气相色谱-热能分析联用法:GB/T 23228-2008[S].北京:中国标准出版社,2009.
-
[29]
国家烟草专卖局.烟草及烟草制品感官评价方法:YC/T 138-1998[S].北京:中国标准出版社,1998.
-
[30]
李荣一,金东柱.纤维长度和粗度对纸张结构性能的影响[J].中国造纸,2018,37(7):49-52.
-
[31]
王娜,曾海斌,高国强,等.五种松属树种针叶长度与叶水力功能、结构的关系[J].湖南生态科学学报, 2024,11(2):26-34.
-
[32]
邓少鹏,杨光远,彭三文,等.纸质滤棒结构重组实验及产品性能研究[J].造纸装备及材料,2024,53(10):1-3.
-
[33]
王丽珍,李晓天,王俊跃. TEMPO氧化结合高压均质制备向日葵秸皮纤维素纳米纤维[J].中国造纸学报, 2025,40(2):26-33.
-
[34]
徐一鑫,石大为,曹凯伦,等.超声-TEMPO氧化法制备胡麻纤维素纳米纤维[J].轻纺工业与技术,2025, 54(2):16-19.
-
[35]
叶剑,徐卫城,陈欢欢,等. TEMPO氧化预处理对竹浆纤维性能的影响[J].纸和造纸,2021,40(5):6-9.
-
[36]
吴明月,戴鑫建,王鑫,等. TEMPO氧化处理调控轻木细胞壁纳米结构[J].木材科学与技术,2024,38(6):1-7.
-
[37]
刘刚,韩卿,夏安军. TEMPO选择性催化氧化对纸浆成纸性能的影响[J].中华纸业,2008,29(7):50-53.
-
