不同特性烟丝应力松弛性能的特征规律研究
Study on characteristic laws of stress relaxation performance of cut tobacco with different properties
-
摘要: 【目的】 研究不同特性烟丝的应力松弛规律及流变学特性。【方法】 以不同产区、部位、切丝宽度的烟丝及所卷制的中支卷烟为研究对象,通过测定应力松弛时间比率、平衡应力、黏性指数等参数,结合烟丝应力松弛流变学模型,分析烟丝特性与烟支物理指标对烟丝应力松弛性能的影响规律。【结果】 下部烟丝的应力松弛时间比率显著低于上部和中部烟丝,且平衡应力较高,表现出相对更好的流变力学稳定性;切丝宽度为0.8 mm时,烟丝的弹性和填充性能均达到相对最优水平;不同产区烟丝样品的应力松弛性能表现出明显差异,云南烟丝样品的应力松弛时间比率较高、较为柔软,河南烟丝样品具有较低的应力松弛时间比率和较好的弹性;平衡应力与修正封闭吸阻存在较强的相关性,相关系数达0.81。【结论】 烟丝应力松弛性能随产区、部位及切丝宽度的不同呈现规律性变化,平衡应力等流变学参数相较于填充值能更全面地反映烟丝的力学性能,这为制丝与卷接关联性研究提供了新思路。Abstract: 【Objective】 To investigate the stress relaxation behavior and rheological properties of cut tobacco with different properties. 【Methods】 Cut tobacco with varied producing areas, stalk positions and cut widths, as well as medium-diameter cigarettes processed from such cut tobacco, were adopted as the research objects. The effects of cut tobacco properties and cigarette physical indicators on the stress relaxation performance of cut tobacco were analyzed by determining key parameters including stress relaxation time ratio, equilibrium stress and viscosity index, in combination with the rheological model for cut tobacco stress relaxation. 【Results】 The stress relaxation time ratio of lower cut tobacco was significantly lower than that of upper and middle cut tobacco, accompanied by greater equilibrium stress, indicating relatively superior rheological mechanical stability. Both the elasticity and filling capacity of cut tobacco reached the relatively optimum level at a cut width of 0.8 mm. Significant differences were observed in the stress relaxation performance of cut tobacco samples from different producing areas: Yunnan samples exhibited a higher stress relaxation time ratio and softer texture, whereas Henan samples possessed a lower stress relaxation time ratio and favorable elasticity. A strong correlation existed between equilibrium stress and corrected closed resistance, with a correlation coefficient of 0.81. 【Conclusion】 The stress relaxation performance of cut tobacco varies regularly with variations in producing area, stalk position and cut width. Compared with filling value, rheological parameters including equilibrium stress can more comprehensively characterize the mechanical properties of cut tobacco, which offers novel insights into the research on the correlation between tobacco processing and cigarette making.
-
Key words:
- cut tobacco /
- stress relaxation /
- rheology /
- equilibrium stress /
- cigarette physical indicator
-
-
[1]
国家烟草专卖局.卷烟工艺规范[M].北京:中国轻工业出版社,2016. National Tobacco Monopoly Administration.Cigarette manufacturing process specifications[M].Beijing:China Light Industry Press,2016.
-
[2]
国家烟草专卖局.卷烟 烟丝弹性的测定方法:YC/T 186—2004[S].北京:中国标准出版社,2004. National Technical Committee for Standardization of Tobacco.Cigarettes—Determination of elasticity of cut tobacco:YC/T 186—2004[S].Beijing:Standards Press of China,2004.
-
[3]
王天怡,姚二民,董一雷,等.温度对不同规格卷烟烟丝弹性的影响研究[J].轻工科技,2023,39(6):40-43
,70. WANG T Y,YAO E M,DONG Y L,et al.Study on the influence of temperature on the elasticity of cut tobacco of different specifications[J].Light Industry Science and Technology,2023,39(6):40-43,70. -
[4]
李旭英.草物料压缩流变动力学特性研究及压缩过程优化[D].呼和浩特:内蒙古农业大学,2006. LI X Y.Rheodynamic characteristics of herbage materials in compression and optimization of compression process[D].Huhehaote:Inner Mongolia Agricultural University,2006.
-
[5]
杨明韶.农业物料流变学[M].北京:中国农业出版社,2010. YANG M S.Agricultural material flow mechanics[M].Beijing:China Agricultural Press,2010.
-
[6]
MYHAN R,JACHIMCZYK E.Rheological properties of a straw layer[J].Rheologica Acta,2015,54(1):19-27.
-
[7]
金楠,王红英,王威,等.饲料颗粒成型的应力松弛特性研究[J].饲料工业,2025,46(5):12-18.
JIN N,WANG H Y,WANG W,et al.Study on stress relaxation characteristics of feed pellet molding[J].Feed Industry,2025,46(5):12-18. -
[8]
杜晓雪,郭文斌,王春光,等.饲用甜高粱秸秆应力松弛特性及参数优化的试验研究[J].中国农业大学学报,2019,24(2):123-131.
DU X X,GUO W B,WANG C G,et al.Stress relaxation characteristics and parameters optimization of feed sweet sorghum[J].Journal of China Agricultural University,2019,24(2):123-131. -
[9]
房佳佳,张永,杨明韶,等.紫花苜蓿圆捆机卷压过程的应力松弛特性与模型建立[J].农业工程学报,2018,34(16):50-56.
FANG J J,ZHANG Y,YANG M S,et al.Stress relaxation behavior and modeling of alfalfa during rotary compression[J].Transactions of the Chinese Society of Agricultural Engineering,2018,34(16):50-56. -
[10]
LIN C Y,CHEN Y C,LIN C H,et al.Constitutive equations for analyzing stress relaxation and creep of viscoelastic materials based on standard linear solid model derived with finite loading rate[J].Polymers,2022,14(10):2124.
-
[11]
张强,孙力,邱晔,等.云南烤烟主产区烟叶及其烟气主要化学成分的差异分析[J].云南大学学报(自然科学版),2010,32(S1):87-91.
ZHANG Q,SUN L,QIU Y,et al.Analysis on the differences of principal chemical components and smoke components of flue-cured tobacco in main tobacco-growing areas of Yunnan[J].Journal of Yunnan University (Natural Science Edition),2010,32(S1):87-91. -
[12]
黄中艳,王树会,朱勇,等.云南烤烟5项化学成分含量与其环境生态要素的关系[J].中国农业气象,2007,28(3):312-317.
HUANG Z Y,WANG S H,ZHU Y,et al.Relationships between content of leading chemical components of tobacco leaves and ecological factors in Yunnan Province[J].Chinese Journal of Agrometeorology,2007,28(3):312-317. -
[13]
余建飞,郑福维,卿湘涛,等.湘西烟区气候特征及其对烟叶外观质量和物理特性的影响[J].甘肃农业大学学报,2018,53(5):43-51
,57. YU J F,ZHENG F W,QING X T,et al.Analysis of climate factors and their influence on appearance qualities and physical characteristics of tobacco leaves in Xiangxi tobacco growing areas[J].Journal of Gansu Agricultural University,2018,53(5):43-51,57. -
[14]
韩顺起,付丽丽,丁伟,等.烟丝压缩过程中应力松弛模型的建立[J].烟草科技,2023,56(6):78-84.
HAN S Q,FU L L,DING W,et al.Stress relaxation modeling for cut tobacco during compression[J].Tobacco Science & Technology,2023,56(6):78-84. -
[15]
郭文斌,王志鹏,候智博,等.秸秆-薯渣混合物料应力松弛分数阶模型的建立及参数分析[J].农业工程学报,2021,37(13):284-290.
GUO W B,WANG Z P,HOU Z B,et al.Parameter analysis and development of fractional Calculus model for stress relaxation of cornstalk and potato residues[J].Transactions of the Chinese Society of Agricultural Engineering,2021,37(13):284-290. -
[16]
韩顺起.烟草堆积散体压缩过程中的流变学行为及影响因素研究[D].郑州:中国烟草总公司郑州烟草研究院,2023. HAN S Q.Study on rheological behavior and influencing factors of tobacco pile bulk compression[D].Zhengzhou:Zhengzhou Tobacco Research Institute of China National Tobacco Corporation,2023.
-
[17]
国家烟草专卖局.烟草及烟草制品 试样的制备和水分测定 烘箱法:YC/T 31—1996[S].北京:中国标准出版社,1996. State Tobacco Monopoly Administration.Tobacco and tobacco products—Preparationof test sample and determination of water content—Oven method:YC/T 31—1996[S].Beijing:Standards Press of China,1996.
-
[18]
国家烟草专卖局.卷烟 烟丝填充值的测定:YC/T 152—2001[S].北京:中国标准出版社,2001. State Tobacco Monopoly Administration.Cigarette—Determination of filling power of cut tobacco:YC/T 152—2001[S].Beijing:Standards Press of China,2001.
-
[19]
刘丽,许自成.烟草叶质重研究进展[J].安徽农业科学,2007,35(35):11487-11489.
LIU L,XU Z C.Research advances of leaf specific weight of flue-cured tobacco[J].Journal of Anhui Agricultural Sciences,2007,35(35):11487-11489. -
[20]
周定鹏,张鑫,徐玮杰,等.中国八大生态区烤烟理化指标特征及模块配方设计分析[J].中南农业科技,2025,46(5):88-94.
ZHOU D P,ZHANG X,XU W J,et al.Analysis of the characteristics of physicochemical indicators of roasted tobacco in the eight major ecological zones of China and the design of theular formula[J].South-Central Agricultural Science and Technology,2025,46(5):88-94. -
[21]
马爱国,宋德伟,孙在明,等.不同部位烟叶外观特征与内在质量分析研究[J].山东农业科学,2009,41(5):48-51.
MA A G,SONG D W,SUN Z M,et al.Study on appearance characters and internal quality of different stalk position flue-cured tobacco leaves[J].Shandong Agricultural Sciences,2009,41(5):48-51. -
[22]
卢幼祥,叶浩,邵名伟,等.切丝宽度对细支卷烟质量影响分析[J].湖南文理学院学报(自然科学版),2023,35(1):53-57
,88. LU Y X,YE H,SHAO M W,et al.Analysis of the influence of cut width on the quality of thin.cigarettes[J].Journal of Hunan University of Arts and Science (Science and Technology),2023,35(1):53-57,88. -
[23]
郭华诚,吴艳艳,张峻松,等.切丝宽度对细支烟卷制质量、主流烟气及感官质量的影响[J].食品与机械,2021,37(2):194-198.
GUO H C,WU Y Y,ZHANG J S,et al.Influences of cut tobacco width on physical indexes,mainstream smoke and sensory quality of slim cigarette[J].Food & Machinery,2021,37(2):194-198. -
[24]
周之武.卷烟吸阻影响因素研究综述[J].轻工科技,2020,36(11):9-10.
ZHOU Z W.A review of factors affecting cigarette draw resistance[J].Light Industry Science and Technology,2020,36(11):9-10. -
[25]
朱宁宁,董利利,冯银龙,等.影响卷烟吸阻变化的多因素研究[J].食品工业,2023,44(5):134-139.
ZHU N N,DONG L L,FENG Y L,et al.Study on the multi factors influencing the change of cigarette resistance[J].The Food Industry,2023,44(5):134-139. -
[26]
吴晓炯,居雷,张宇,等.基于Copula函数和GMM联用的卷烟理想烟柱质量与压降物理模型[J].烟草科技,2026,59(1):89-99.
WU X J,JU L,ZHANG Y,et al.An ideal mass and pressure drop physical model for tobacco rods based on the combination of Copula function and Gaussian mixture model[J].Tobacco Science & Technology,2026,59(1):89-99.
-
