应用离散元法表征烟丝尺寸对其柔软性的力学影响
Mechanical effects of cut tobacco sizes on softness characterized by discrete element method
-
摘要: 为明确烟丝不同尺寸及比例对其柔软性的影响,探究引起烟丝柔软性差异的原因,借助离散元法构建的质构仪仿真模型测量烟丝柔软性,分析各尺寸烟丝在测量过程中的受力差异及对力链演变的影响,并通过调整烟丝尺寸配比,分析烟丝柔软性的变化规律。结果表明:大于3.35 mm和小于1.00 mm的烟丝占比越高,烟丝柔软性越差;1.00~2.50 mm和2.50~3.35 mm的烟丝占比越高,烟丝柔软性越佳;2.50~3.35 mm的烟丝对测量过程中的烟丝受力表现影响最大。烟丝平均受力随烟丝尺寸的下降而下降,且变得更加均匀。柔软性好的烟丝样品,烟丝间中等及高强度力链数量更少,中等强度力链分布更均匀。各尺寸烟丝与烟丝整体之间的中低强度接触比例随着烟丝尺寸降低而增加。合理提高中丝率和短丝率有利于改善烟丝柔软性,较高的长丝率和碎丝率会使烟丝柔软性变差。适当提高1.00~3.35 mm烟丝占比、降低3.35 mm以上及1.00 mm以下烟丝占比,有利于整体改善烟丝在外部载荷作用下的力学性能,提高其柔软性。Abstract: To investigate the effects of cut tobacco size distribution on softness and elucidate the underlying mechanisms causing variations in softness, a texture analyzer simulation model was developed using the discrete element method (DEM). This model was employed to measure cut tobacco softness, analyze the force response differences among various size fractions during testing, and explore their impacts on force chain evolution. By adjusting the size ratios, the variation patterns of softness were systematically examined. The results indicated that a higher proportion of tobacco particles exceeding 3.35 mm or below 1.00 mm was associated with reduced softness, while an increased proportion of tobacco within the size ranges of 1.00~2.50 mm and 2.50~3.35 mm correlated with improved softness. Tobacco particles in the 2.50~3.35 mm size range exerted the greatest influence on the force response during measurement. The average force experienced by tobacco particles decreased with decreasing particle size and became more uniformly distributed. Softer tobacco samples exhibited fewer medium-and high-strength force chains, which were also more uniformly distributed. The proportion of low-to-medium strength contacts between different size fractions increased with decreasing particle size. Rational increases in medium-sized (1.00~2.50 mm) and short (2.50~3.35 mm) tobacco fractions improved softness, while excessive proportions of long (>3.35 mm) and fine (<1.00 mm) particles degraded softness. Optimizing the size distribution by increasing the proportion of 1.00~3.35 mm particles and reducing fractions outside this range enhanced both the mechanical performance and softness under external loading.
-
-
[1]
于建军.卷烟工艺学[M].2版.北京:中国农业出版社,2009.
-
[2]
李永宽,杨耀伟,冯剑,等.提高烟丝适用性的综合质量评价方法[J].河南化工,2013,30(S1):14-17.
-
[3]
-
[4]
付秋娟,孙婷婷,窦玉青,等.初烤烟叶柔软度及其与烟叶主要理化指标的关系[J].烟草科技,2021,54(5):77-81.
-
[5]
陈天才,耿红梅,王振国,等.基于偏最小二乘回归的挂灰程度和柔软性对烟叶质量的影响分析[J].安徽农业科学,2023,51(6):177-181.
-
[6]
沈进,宋成剑,胡梦岩.基于质构仪的造纸法再造烟叶柔软度评价方法[J].烟草科技,2020,53(7):87-91.
-
[7]
李晓,贺紫玺,方世航,等.烟丝柔软性的检测及其与卷制质量的关系[J].云南农业大学学报(自然科学),2023,38(2):314-323.
-
[8]
李博宇,范兴,乔俊峰,等.数值模拟在烟草领域中的应用与展望[J].烟草科技,2022,55(4):89-100.
-
[9]
BOAC J M,KINGSLY AMBROSE R P,CASADA M E,et al.Applications of discrete element method in modeling of grain postharvest operations[J].Food Engineering Reviews,2014,6(4):128-149.
-
[10]
袁晓明,王超,阎鹏,等.离散元法在工农业上的应用研究综述[J].机械设计,2016,33(9):1-9.
-
[11]
吴玉生,王道铨,李鹏超.基于离散元法的烟丝加香机优化设计[J].烟草科技,2021,54(12):87-94.
-
[12]
汤达伟,方鑫,杨格,等.离散元法在卷烟包装机组烟库仿真设计中的应用[J].烟草科技,2020,53(9):94-99.
-
[13]
朱立平,袁竹林,闫亚明,等.基于离散单元法的丝状颗粒传热数学模型[J].化工学报,2012,63(7):2051-2058.
-
[14]
陈有锦.滚筒式烟草加料机加料过程分析及参数优化研究[D].昆明:昆明理工大学,2023.
-
[15]
张秀丽,吴亚文,李建华,等.烟草颗粒肥配比混施装置的设计与试验[J].河南农业大学学报,2020,54(5):829-835.
-
[16]
郑文鑫,林恒矗,何金成,等.烟草除秆清根刀具作业过程离散元仿真分析[J].福建农林大学学报(自然科学版),2023,52(4):563-572.
-
[17]
-
[18]
杜海君,雷霆,张永安,等.苜蓿振动压缩成型过程中的力链演变[J].农业工程学报,2022,38(2):33-40.
-
[19]
THAKUR S C,MORRISSEY J P,SUN J,et al.Micromechanical analysis of cohesive granular materials using the discrete element method with an adhesive elasto-plastic contact model[J].Granular Matter,2014,16(3):383-400.
-
[20]
GENG F,LI Y M,WANG X Y,et al.Simulation of dynamic processes on flexible filamentous particles in the transverse section of a rotary dryer and its comparison with ideo-imaging experiments[J].Powder Technology,2011,207(1/2/3):175-182.
-
[21]
金浩,蒋明洋,徐超,等.基于离散元法的柔性片烟建模及仿真参数标定[J].沈阳农业大学学报,2023,54(5):563-571.
-
[22]
-
[23]
孙玉刚,党耀国.灰色T型关联度的改进[J].系统工程理论与实践,2008,28(4):135-139.
-
[24]
李孟霞,李军营,文国松,等.影响云南清香型烟叶化学品质的土壤因子分析[J].西南农业学报,2021,34(2):340-346.
-
[25]
BARRETO D,O’SULLIVAN C.The influence of inter-particle friction and the intermediate stress ratio on soil response under generalised stress conditions[J].Granular Matter,2012,14(4):505-521.
-
[26]
孙其诚,金峰,王光谦,等.二维颗粒体系单轴压缩形成的力链结构[J].物理学报,2010,59(1):30-37.
-
[27]
CAVARRETTA I,O’SULLIVAN C.The mechanics of rigid irregular particles subject to uniaxial compression[J].Géotechnique,2012,62(8):681-692.
-
[28]
范林,王春光,王洪波,等.揉碎玉米秸秆可压缩性研究[J].农业机械学报,2008,39(11):76-80.
-
