周向型加热卷烟烟芯段逐口热解过程的空间表征
Study on the spatial characterization of the puff-by-puff pyrolysis process in circumferentially heated cigarette core segments
-
摘要: 【目的】探究周向型加热卷烟逐口抽吸过程中不同部位烟芯材料的热解过程。【方法】以逐口抽吸后的加热卷烟烟芯材料为原料,采用自研空间分离方法,将其从空间上分离为9个不同部位,并采用热重分析仪和氢火焰离子化质谱(GC-FID)进行分析,考查逐口抽吸后不同部位烟芯材料的理化特性差异。【结果】逐口抽吸过程中烟芯的炭化区域随抽吸口数增加,由中后段外层逐步向内层、前段扩散,最终抽吸段结束时烟芯整体发生明显炭化。烟芯材料的热解过程可分为4个阶段,其中阶段Ⅱ为主要的热失重阶段,对应热失重温度区间为209~415 ℃,DTG曲线上峰A主要由烟芯材料中甘油、烟碱和1,2-丙二醇等化学成分的受热释放所引起。随抽吸口数增加,相同部位烟芯材料DTG曲线峰A的最大质量损失速率整体上呈降低趋势;第5口抽吸后,不同部位烟芯材料DTG曲线峰A的最大质量损失速率呈现径向上按前内、前中、前外和轴向上前内、后内、中内顺序由大到小的变化趋势。逐口抽吸过程中,甘油、烟碱和1,2-丙二醇在烟芯材料中的总残留量逐口降低;抽吸结束后,这3种成分在烟芯材料中的总残留量分别为初始含量的21.90%,2.98%和0.31%。逐口抽吸过程中,甘油、烟碱和1,2-丙二醇在烟芯材料中的残留量在径向上均呈现按内层、中层、外层顺序由大到小的分布,在轴向上由大到小的顺序由前段、中段、后段变为前段、后段、中段的分布。【结论】不同化合物在烟芯材料中残留量的逐口变化情况与其热解特性相一致,其在烟芯材料的空间分布情况受到温度和其沸点的影响。Abstract: 【Objective】This study aimed to investigate the pyrolysis process of tobacco core materials at different positions in circumferentially heated cigarettes during puff-by-puff smoking.【Methods】Tobacco core materials from heated cigarettes after puff-by-puff smoking were used as raw materials. A self-developed spatial separation method was used to divide the tobacco core into nine different positions. A thermogravimetric analyzer and gas chromatography-flame ionization detection (GC-FID) were used to analyze the physicochemical property differences of tobacco core materials at different positions after puff-by-puff smoking.【Results】During puff-by-puff smoking, the carbonization region of the tobacco core gradually spread from the outer layer of the middle-rear section to the inner layer and the front section with increasing puff number, and the entire tobacco core showed significant carbonization by the end of the smoking session. The pyrolysis process of tobacco core materials could be divided into four stages, among which Stage Ⅱ was the main mass-loss stage, corresponding to a temperature range of 209~415 ℃. Peak A on the DTG curve mainly resulted from the thermal release of chemical components such as glycerol, nicotine, and 1,2-propanediol in the tobacco core materials. With increasing puff number, the maximum mass-loss rate of Peak A on the DTG curve for tobacco core materials at the same position showed an overall decreasing trend. After the fifth puff, the maximum mass-loss rate of Peak A on the DTG curve for tobacco core materials at different positions decreased in the order of front-inner, front-middle, and front-outer in the radial direction, and in the order of front-inner, rear-inner, and middle-inner in the axial direction. During puff-by-puff smoking, the total residual amounts of glycerol, nicotine, and 1,2-propanediol in the tobacco core materials decreased puff by puff. After the smoking session, the total residual amounts of the three components in the tobacco core materials were 21.90%, 2.98%, and 0.31% of their initial contents, respectively. During puff-by-puff smoking, the residual amounts of glycerol, nicotine, and 1,2-propanediol in the tobacco core materials all decreased in the order of inner layer, middle layer, and outer layer in the radial direction, while their decreasing order in the axial direction changed from front section, middle section, and rear section to front section, rear section, and middle section.【Conclusion】The puff-by-puff changes in the residual amounts of different compounds in tobacco core materials were consistent with their pyrolysis characteristics, and their spatial distribution in the tobacco core materials was affected by temperature and their boiling points.
-
Key words:
- heated tobacco product /
- thermogravimetric analysis /
- GC-FID /
- spatial characterization
-
-
[1]
Sun T Z,Anandan A,Lim C C W,et al.Global prevalence of heated tobacco product use,2015-22:a systematic review and meta-analysis[J].Addiction,2023,118(8):1430-1444.
-
[2]
Takahashi Y,Kanemaru Y,Fukushima T,et al.Chemical analysis and in vitro toxicological evaluation of aerosol from a novel tobacco vapor product:a comparison with cigarette smoke[J].Regulatory Toxicology and Pharmacology,2018,92:94-103.
-
[3]
李翔,谢复炜,刘惠民.新型烟草制品毒理学评价研究进展[J].烟草科技,2016,49(1):88-93.
Li X,Xie F W,Liu H M.Recent advances in toxicological evaluation of novel tobacco products[J].Tobacco Science & Technology,2016,49(1):88-93. -
[4]
刘亚丽,王金棒,郑新章,等.加热不燃烧烟草制品发展现状及展望[J].中国烟草学报,2018,24(4):91-106.
Liu Y L,Wang J B,Zheng X Z,et al.Current status and prospect of heat-not-burn tobacco products[J].Acta Tabacaria Sinica,2018,24(4):91-106. -
[5]
龚淑果,刘巍,黄平,等.加热不燃烧卷烟烟气主要成分的逐口释放行为[J].烟草科技,2019,52(2):62-71.
Gong S G,Liu W,Huang P,et al.Puff-by-puff release of main aerosol components from two commercial heat-not-burn tobacco products[J].Tobacco Science & Technology,2019,52(2):62-71. -
[6]
崔华鹏,陈黎,樊美娟,等.电加热卷烟气溶胶物理特性的表征[J].轻工学报,2022,37(2):87-93
,101. Cui H P,Chen L,Fan M J,et al.Characterization of physical properties of aerosol from electrically heated cigarette[J].Journal of Light Industry,2022,37(2):87-93,101. -
[7]
Cozzani V,Barontini F,Mcgrath T,et al.An experimental investigation into the operation of an electrically heated tobacco system[J].Thermochimica Acta,2020,684:178475.
-
[8]
崔华鹏,陈黎,樊美娟,等.加热温度对加热卷烟气溶胶物理特性的影响[J].烟草科技,2022,55(4):36-41.
Cui H P,Chen L,Fan M J,et al.Effects of heating temperature on physical properties of aerosol from heated tobacco products[J].Tobacco Science & Technology,2022,55(4):36-41. -
[9]
孟璠,崔华鹏,陈黎,等.不同加热温度加热卷烟抽吸过程中烟芯段气溶胶的动态分布[J].烟草科技,2023,56(3):41-50.
Meng F,Cui H P,Chen L,et al.Dynamic distribution of aerosol inside tobacco section of a heated tobacco product during smoking at different heating temperatures[J].Tobacco Science & Technology,2023,56(3):41-50. -
[10]
王乐,王亚林,李志强,等.电加热卷烟烟芯段温度分布和烟气关键成分逐口变化:第1部分 实验[J].烟草科技,2021,54(3):31-39.
Wang L,Wang Y L,Li Z Q,et al.Temperature distribution in tobacco section of an electrically heated cigarette and puff-by-puff variation of key smoke components:part 1.Experiments[J].Tobacco Science & Technology,2021,54(3):31-39. -
[11]
张璟,王康,谭健,等.针式中心加热卷烟抽吸后烟丝中烟碱和雾化剂的径向变化[J].烟草科技,2023,56(1):66-73.
Zhang J,Wang K,Tan J,et al.Radial distributions of nicotine and atomizing agents in tobacco section of a needle-style centrally heated tobacco product after smoking[J].Tobacco Science & Technology,2023,56(1):66-73. -
[12]
肖卫强,周国俊,蒋健,等.加热卷烟制品传热与烟气流动过程数值模拟[J].华东理工大学学报(自然科学版),2021,47(1):35-40.
Xiao W Q,Zhou G J,Jiang J,et al.Numerical simulation of heat transfer and smoke flow of heated cigarette product[J].Journal of East China University of Science and Technology,2021,47(1):35-40. -
[13]
吴键,管庆林,汤晓东,等.八大香型烤烟的低温热解特性及香味物质释放差异分析[J].河南农业科学,2026,55(6):156-168.
Wu J,Guan Q L,Tang X D,et al.Analysis of low-temperature pyrolysis characteristics and aroma compound release differences in eight aroma styles of flue-cured tobacco[J].Journal of Henan Agricultural Sciences, 2026,55(6):156-168. -
[14]
王乐,王亚林,李志强,等.电加热卷烟烟芯段温度分布和烟气关键成分逐口变化:第2部分模拟[J].烟草科技,2021,54(6):58-64.
Wang L,Wang Y L,Li Z Q,et al.Temperature distribution in tobacco section of an electrically heated cigarette and puff-by-puff releases of key smoke components:part 2 Simulation[J].Tobacco Science & Technology,2021,54(6):58-64. -
[15]
高峄涵,黄洁洁,王雨青,等.电加热卷烟传热与原料组分变化的数值模拟[J].烟草科技,2023,56(12):67-75.
Gao Y H,Huang J J,Wang Y Q,et al.Numerical simulation of heat transfer and main aerosol constituents released from electrically heated tobacco products[J].Tobacco Science & Technology,2023,56(12):67-75. -
[16]
温光和,肯生叶,李峰,等.加热不燃烧卷烟烟草材料中1,2-丙二醇、丙三醇和烟碱的测定[J].中国烟草科学,2019,40(4):69-75.
Wen G H,Ken S Y,Li F,et al.Determination of 1,2-propylene glycol,glycerol and nicotine of tobacco materials in heat-not-burn cigarettes[J].Chinese Tobacco Science,2019,40(4):69-75. -
[17]
王秦超,卢平,黄震,等.生物质低温热解炭化特性的实验研究[J].中国电机工程学报,2012,32(S1):121-126.
Wang Q C,Lu P,Huang Z,et al.Experimental study on low temperature pyrolysis of biomass[J].Proceedings of the CSEE,2012,32(S1):121-126. -
[18]
严伟,陈智豪,盛奎川.适宜炭化温度及时间改善生物质成型炭品质[J].农业工程学报,2015,31(24):245-249.
Yan W,Chen Z H,Sheng K C.Carbonization temperature and time improving quality of charcoal briquettes[J].Transactions of the Chinese Society of Agricultural Engineering,2015,31(24):245-249. -
[19]
Gao W H,Chen K F,Xiang Z Y,et al.Kinetic study on pyrolysis of tobacco residues from the cigarette industry[J].Industrial Crops and Products,2013,44:152-157.
-
[20]
Wu W X,Mei Y F,Zhang L,et al.Kinetics and reaction chemistry of pyrolysis and combustion of tobacco waste[J].Fuel,2015,156:71-80.
-
[21]
Zhu L J,Xu J,Dai Y J,et al.Mechanism study of tobacco pyrolysis based on the analysis of characteristic products and in-situ identification of functional groups evolution on pyrolytic char[J].Journal of Analytical and Applied Pyrolysis,2022,167:105681.
-
[22]
Li X,Zhao Q Q,Han M,et al.Pyrolysis characteristics and kinetic analysis of tobacco stem pretreated with different solvents[J].Biomass Conversion and Biorefinery,2024,14(1):501-515.
-
[23]
马俊,王晓斌,朱绍胤,等.云南烟叶加热状态下的失重及产物释放特性的热重-质谱联用分析[J].云南农业大学学报, 2025,40(5):78-84.
Ma J,Wang X B,Zhu S Y,et al.TG-MS analysis of weight loss and product release charac-teristics of Yunnan tobacco leaves under heating[J].Journal of Yunnan Agricultural University (Social Science),2025,40(5): 78-84. -
[24]
杜赫,王轶群,乔月梅,等.基于加热卷烟的国内外烤烟低温热解特性研究[J].农产品加工,2025(12):74-78. Du H,Wang Y Q,Qiao Y M,et al.Low-temperature pyrolysis characteristics of the domestic and foreign flue-cured tobacco based on heated cigarettes[J].Agricultural Products Processing,2025
(12):74-78. -
[25]
梁淼,刘语煊,朱海波,等.不同类型烟叶热失重特性及分步热释放香味成分分析[J].河南农业科学,2025,54(3):157-169.
Liang M,Liu Y X,Zhu H B,et al.Analysis of thermogravimetric characteristics and stepwise thermal release aroma components of different types of tobacco[J].Journal of Henan Agricultural Sciences,2025,54(3):157-169. -
[26]
苏小平,申涛,张平,等.TG和Py-GC/MS研究不同烟草的热解特性[J].西北民族大学学报(自然科学版),2024,45(1):14-24.
Su X P,Shen T,Zhang P,et al.TG and py-GC/MS studies on pyrolysis characteristics of different cut-tobacco[J].Journal of Northwest University for Nationalities (Natural Science),2024,45(1):14-24. -
[27]
刘广超,刘鸿,张玮,等.调节湿度对国外两款市售加热卷烟烟气主要成分逐口释放行为的影响[J].烟草科技,2021,54(9):40-47.
Liu G C,Liu H,Zhang W,et al.Effects of conditioning humidity on puff-by-puff releases of main aerosol components from two foreign commercial heated tobacco products[J].Tobacco Science & Technology,2021,54(9):40-47. -
[28]
周慧明,刘鸿,刘广超,等.自制研究平台不同加热温度下电加热卷烟主要成分的释放行为[J].烟草科技,2021,54(6):50-57.
Zhou H M,Liu H,Liu G C,et al.Release behaviors of main aerosol components from electrically heated cigarettes at different temperatures based on a bespoke test platform[J].Tobacco Science & Technology,2021,54(6):50-57. -
[29]
司晓喜,罗萌柔,尤俊衡,等.加热温度对气溶胶化学成分释放的影响[J].烟草科技,2022,55(12):46-58.
Si X X,Luo M R,You J H,et al.Effects of heating temperature on releases of chemical components in aerosol[J].Tobacco Science & Technology,2022,55(12):46-58.
-
